Commissioning Report
BA8230
145
Parameter setting
Object-Nr.
Parameter
Default setting
Unit
Value
01=DISPLAY
2009
Drive Name
...................
206A
Date/Time
...................
02=Application Par.
3225
Speed limit
1499.91
1/min
................
3220
Ref. overspeed
1)
1800
1/min
................
4282
Crnt.lmt.max.mot.
144.4
%
................
4283
Crnt.lmt.max.gen.
100.0
%
................
4281
Crnt.lmt.nom.gen.
1)
100.0
%
................
4280
Crnt.lmt.nom.mot.
1)
100.0
%
................
3810
Ramp up
2000.0
ms
................
3812
Ramp down
5000.0
ms
................
3814
Ramp fast stop
500.0
ms
................
3710
Motpot ramp up
10.000
s
................
3711
Motpot ramp down
10.000
s
................
3712
Motpot n-max
1499.9
1/min
................
3713
Motpot n-min
0.0
1/min
................
3204
Jogging speed
29.85
1/min
................
3200
Fixed speed 1
149.97
1/min
................
3201
Fixed speed 2
299.95
1/min
................
3202
Fixed speed 3
449.92
1/min
................
3203
Fixed speed 4
599.89
1/min
................
3830
Skip speed 1
750.0
1/min
................
3831
Skip band 1
0.0
1/min
................
3832
Skip speed 2
1500.1
1/min
................
3833
Skip band 2
0.0
1/min
................
3834
Skip speed 3
2250.1
1/min
................
3835
Skip band 3
0.0
1/min
................
03=CONFIGURATION
3103
Reaction OFF
Discharge dc link
................
3107
Motpot reset
Reset at OFF
................
3108
Lock monitor
Yes
................
2069
Auto Restart Time
0.000 s
................
3260
Manual - control
Control or Terminal
................
3A80
Manual - demand
Motpot
................
3261
AUTO - control
Terminal
................
3A82
AUTO - demand
Motpot
................
3105
MAN/AUTO c/over
At standstill
................
3109
Invert:21/22
No
................
4012
capture mode
2)
No
Direction drive
1
................
3120
Kinetik support
1)
No
................
205D
Parameter Set Nr.
1
................
205F
Copy Target: Set Nr.
2)
0
................
3121
Term.ParSet chan.
Disabled
................
439A
Puls frequency
2)
3
kHz
................
1)
Protection Level 1
2)
Protection Level 2
Code:
Date
Comm. No.
Contac.
FB No.:
Commissioning report
8230 frequency inverter
Drive data
Check.
Serial.No.:
Sheet 5
