Transport, Installation and Connection
BA8230
71
Note:
The cable cross-sections stated in Table 23 can only be considered general
guidelines. The cable dimensions must satisfy the regulations and any works
standards applicable at the installation.
8230 frequency inverter
Type
Mains connection
Motor connection
Screw connection
Motor + Mains connection
Recommended
copper cable
cross-sections
Applicable
overload
protection NH
fuse
Recommended
copper cable
cross-sections
Steel screw
Strength class 8.8,
not greased
Tightening
torque
Max. direct
single
connection
cross-section
at the unit
[mm²]
[mm²]
[Nm]
[mm²]
8231
2 x 3 x 95
315 A
2 x 3 x 95
M12
92
200
8232
2 x 3 x 120
355 A
2 x 3 x 120
M12
92
200
8233
2 x 3 x 150
400 A
2 x 3 x 150
M12
92
200
8234
2 x 3 x 185
500 A
2 x 3 x 185
M12
92
200
Table 23: Cable connections
Note concerning motor connection
The following main factors must be taken into consideration for connecting motors to
the 8230 frequency inverter:
•
8230 frequency inverter unit type: As standard the response threshold for earth
fault
detection on the motor side is 10 % I
N
.
•
8230 frequency inverter pulse frequency
•
Motor insulation system: Details from the motor manufacturer concerning the max.
motor voltage/current in the motor terminal box, suitability for inverter operation
•
Cable type: Screened, with armouring or without screen
•
Effective cable length: Parallel cables, group supply
•
Cable cross-section: Voltage drop
≤
1.75 % or
≤
3 %
Suitable screened heavy current cable 0.6/1 kV
Cross-section [mm
2
]
Type
Manufacturer
to 25
Ölfex-Servo - 730 CY
Lappkabel
10 ... 120
Protoflex-EMV-CY
2YSLCY-J
Siemens
10 ... 185
NYCWY 3x XX/Y
(für Y jeweils größter Wert)
Normkabel
