Electrical installation
Connection of AS interface
5
EDK71MMXXX−010 DE/EN/FR 5.0
91
L
)
Note!
The AS interface is only active with starttec type E71MM402FxAxxx! −23−
)
Note!
If the mains voltage is switched on and no supply voltage DC 24 V is
applied, the AS−i status bits have the value TRUE. This may cause the status
messages to be misanalysed (e. g. "ready for operation").
Remedy:
l Monitor the incoming cable of the supply voltage DC 24 V for wire
breakage. The wire breakage monitoring must be integrated into the
safety chain of the machine/system.
or
l Assign an AS−i status bit with the signal "TRIP":
– C0415/5 = 25 or C0415/6 = 25
– Then, "TRIP" is also signalling, when the supply voltage DC 24 V is not
applied anymore.
Communications data
Protocol / communication medium AS−I
Network topology Tree
Node Slave
Slave profile S−7.F (IO code: 7
hex
, ID code: F
hex
)
Operating parameters F
hex
Data structure 3 AS−I data bits (D0, D1, D2) to starttec
2 AS−I data bits (D0, D1) from starttec
Max. number of nodes 31
Transfer rate [kbit/s] 167
Cycle time [ms] 5 ms (with 31 nodes)
Max. bus length [m] 100
