Commissioning
Code table
7
EDK71MMXXX−010 DE/EN/FR 5.0
107
L
)
Note!
Settings for "Motor 2" are not relevant for the starttec "Motor starter
type 1"! (Corresponding information applies only to the starttec "Motor
starter type 2" for operation with 2 motors.)
How to read the code table −29−
Column Abbreviation Meaning
Code Cxxxx Code Cxxxx Parameter value is accepted immediately
(ONLINE)
1 Subcode 1 of Cxxxx
2 Subcode 2 of Cxxxx
Cxxxx
v
Changed parameter of the code is adopted after pressing
v
Cxxxx
s
Changed parameter of the code is adopted after pressing
v
if the
controller is inhibited
uSEr
Code is available in the Lenze setting in the
uSEr
menu. The
uSEr
menu is active after every mains connection.
Designation Designation of the code
Lenze Lenze setting (value at delivery or after restoring the delivery state with
C0002)
à The "IMPORTANT" column contains additional information
Selection 1 {%} 99 Min. value{unit} max. value
IMPORTANT − Short important explanations
Code Setting options IMPORTANT
No. Designation Lenze Selection
C0002
s
uSEr
Parameter set
management 0 0 Ready PAR1 ... PAR4:
l Parameter sets of the
drive controller
l PAR1 ... PAR4 also
contain the parameters
form the system bus
(CAN) function module
l In PAR1 ... PAR4,
C0005, C0408, C0409,
C0410 and C0411 can
be set individually
FPAR1:
l Module−specific
parameter set of the
fieldbus function
modules LECOM−B,
INTERBUS,
DeviceNet/CANopen,
PROFIBUS−DP
l FPAR1 is stored in the
function module
