This documentation applies to the starttec motor starter starting at device status
E71MM402 _ x A XXX 2A 22
Type
AS interface
_ = not active
F = active
DC voltage of spring−operated brake
2 = 205 VDC
4 = 180 VDC
Design
x1x = single drive
x2x = multi−motor operation, change of direction of
rotation
Hardware version
Software version
Illustration legend
X1 (1U, 1V, 1W) Motor connection 1 ^ 84
X1 (2U, 2V, 2W) Not assigned
X1 (L1, L2, L3) Mains connection
X1 (B1, B2, BN) Spring−operated brake connection ^ 88
X1 ( *) Support terminal (e.g. for star point)
X3 Terminal strip X3 (control connections and 24 V supply) ^ 84
X4 Hand terminal or PC (AIF interface) connection
X41 Function module connection (FIF interface)
0 Stepping switch (setting the rated motor current) ^ 96
1 Potentiometer U
0
" (setting the starting voltage U
0
) ^ 96
2 Potentiometer T" (setting acceleration time for soft−starting ramp) ^ 96
3 LEDs (operating status indicators) ^ 128
