7
Commissioning
Code table
EDK71MMXXX−010 DE/EN/FR 5.0
L
124
Code IMPORTANT Setting options
No. Selection Lenze Designation
C0415
v
uSEr
Configuration of
digital output
signals Output of internal digital signals to
terminals or AS interface
1 Digital output
X3/A1
3 Status of motor 1 Motor 1 is running HIGH
Motor 1 is stopped LOW
2 Digital output
X3/A2
4 Status of motor 2 or direction of
rotation Motor 2 is running
or CCW rotation HIGH
Motor 2 stopped
or CW rotation LOW
3 Digital output
X3/A3
5 Status of brake Brake is released HIGH
Brake is applied LOW
4 Digital output
X3/A4
25 TRIP fault message TRIP active HIGH
No fault LOW
5 AS−I status bit
D0
255 Not assigned Only active for variant
E71MM402FxAxxx
6 AS−I status bit
D1
255 Not assigned
Internal digital signals
0 Not assigned
1 PAR−B0 active
2 starttec inhibited
3 Status of motor 1
4 Status of motor 2
5 Status of brake
6 Error in power section
7 fd = 0
8 starttec released/inhibited
9 ...
12 Reserved
13 Overtemperature" warning
14 Reserved
15 CCW rotation
16 Ready for operation
17 PAR−B1 active
18 Reserved
19 Motor overtemperature" warning
(PTC input)
Is generated only if
C0119 = 2
