7
Commissioning
Code table
EDK71MMXXX−010 DE/EN/FR 5.0
L
122
Code IMPORTANT Setting options
No. Selection Lenze Designation
C0410
v
uSEr
Configuration of
digital input
signals Linking external signal sources
with internal digital signals Code is individually
adjustable in four
parameter sets
1 Motor 1
start/stop
1 Digital input X3/E1 Start motor 1 HIGH HIGH
Stop motor 1 LOW
2 Motor 2
start/stop or
direction of
rotation
2 Digital input X3/E2 Start motor 2 or
CCW rotation HIGH
Stop motor 2 or
CW rotation LOW
3 Brake control 3 Digital input X3/E3 Release brake HIGH
Apply brake LOW
4 Reserved 255
Not assigned ...
9 Reserved 255
10 Inhibit/*release
starttec
255 Not assigned Release starttec HIGH
Inhibit starttec LOW
11 External fault 255 Not assigned No fault HIGH
Active external
fault LOW
12 Reset fault 255 Not assigned LOW−HIGH edge resets fault
13 DCTRL1−PAR2/4 255 Not assigned
14 DCTRL1−PAR3/4 255 Not assigned
15 Reserved 255 Not assigned
16 Reserved 255 Not assigned
17 DCTRL1−H/Re 255 DCTRL1−H/Re = 1I All process signals from the
bus system are set to 0.
Release of starttec via
terminal possible:
l Place C0410/13 on the
same source as
C0410/17.
Motor start:
l Place C0410/1 and/2 for
parameter set 2 on
digital input signals.
C0410
v
uSEr
(Cont.)
Configuration of
digital input
signals Linking external signal sources
with internal digital signals Code is individually
adjustable in four
parameter sets
