Function library LenzeIOSystem.lib
Appendix
6.3 Signal functions for analog inputs and outputs EPM−T330
6−7
L
LenzeIOSystem.lib EN 1.7
Parameter
bytes 2/3/4/5 Tolerance 1) Format Signal range Signal function
7E
h
Current measuring 0 ... 20 mA 0.00
0 {0.01 mA}
{1 dec}
+20.00
+27648
A
±0.6 % of limit value
Lower range limit: −
Upper range limit: +23.52 mA
+32511
dec
FF
h
Analog input deactivated
1) The tolerance values were established at 25 °C ambient temperature and 15 conversions/s. No sensor
inaccuracies were taken into consideration.
Output range (channels 2, 3)
Parameter
bytes 2/3/4/5 Signal function Signal range Format Tolerance 1)
00
h
Parameter data in module not overwritten
01
h
Voltage signal output ±10 V −10.00
−16384 {0.01 V}
{1 dec}
+10.00
+16384
B
±0.2 % of limit value
Lower range limit: −12.50 V
−20480
dec
Upper range limit: +12.50 V
+20480
dec
02
h
Voltage signal output 1 ... 5V +1.00
0 {0.01 V}
{1 dec}
+5.00
+16384
B
±0.6 % of limit value
Lower range limit: 0.00 V
−4096
dec
Upper range limit: +6.00 V
+20480
dec
05
h
Voltage signal output 0...10 V 0.00
0 {0.01 V}
{1 dec}
+10.00
+16384
B
±0.4 % of limit value
Lower range limit: −
Upper range limit: +12.50 V
+20480
dec
09
h
Voltage signal output
(complement on two) ±10 V −10.00
−27648 {0.01 V}
{1 dec}
+10.00
+27648
A
±0.2 % of limit value
Lower range limit: −11.76 V
−32512
dec
Upper range limit: +11.76 V
+32511
dec
0A
h
Voltage signal output
(complement on two) 1 ... 5V +1.00
0 {0.01 V}
{1 dec}
+5.00
+27648
A
±0.6 % of limit value
Lower range limit: 0.00 V
−6912
dec
Upper range limit: +5.704 V
+32511
dec
0D
h
Voltage signal output 0...10 V 0.00
0 {0.01 V}
{1 dec}
+10.00
+27648
A
±0.4 % of limit value
Lower range limit: −
Upper range limit: +11.76 V
+32511
dec
03
h
Current signal output ±20 mA −20.00
−16384 {0.01 mA}
{1 dec}
+20.00
+16384
B
±0.3 % of limit value
Lower range limit: −25.00 mA
−20480
dec
Upper range limit: +25.00 mA
+20480
dec
