6.1 Signal functions for analog inputs EPM−T310
Function library LenzeIOSystem.lib
Appendix
6−2
L
LenzeIOSystem.lib EN 1.7
Parameter
bytes 2/3/4/5 Tolerance 1) Format Signal range Signal function
Lower range limit: −11.85 V
−20480 dec
Upper range limit: +11.85 V
20480 dec
2C
h
Current measuring
(complement on two) ±20 mA −20.00
−27648 {0.01 mA}
{1 dec}
+20.00
27648
A ±0.05 % of limit value
Lower range limit: −23.70 mA
−32767 dec
Upper range limit: +23.70 mA
+32767 dec
2D
h
Current measuring
(complement on two) 4 ... 20 mA 4.00
0 {0.01 mA}
{1 dec}
20.00
27648
A ±0.05 % of limit value
Lower range limit: 1.185 mA
−4864 dec
Upper range limit: +22.96 mA
+32767 dec
2E
h
Current measuring 4 ... 20 mA 4.00
0 {0.01 mA}
{1 dec}
20.00
16384
B ±0.2 % of limit value
Lower range limit: 1.185 mA
−2882 dec
Upper range limit: +22.96 mA
+20480 dec
32
h
Resistance measuring with
four−wire connection at 6000 W 0
0 {0.01 W}
{1 dec}
+6000.00
32767 dec
A ±0.05 % of limit value
33
h
at 6000 W 0
0 {0.01 W}
{1 dec}
+6000.00
6000 dec
±0.05 % of limit value
35
h
at 60 W 0
0 {0.01 W} +6000.00
6000 dec
±0.2 % of limit value 2)
36
h
at 600 W 0
0 {0.01 W}
{1 dec}
+600.00
6000 dec
±0.1 % of limit value 2)
37
h
at 3000 W 0
0 {0.01 W}
{1 dec}
+3000.00
30000 dec
±0.1 % of limit value 2)
38
h
at 6000 W 0
0 {0.01 W}
{1 dec}
+6000.00
6000 dec
±0.1 % of limit value 2)
