3.6 Code table
9300 Servo PLC
Appendix
3−42
L
9300 Servo PLC EN 5.0
Code Info Possible settings LCD Code Info
Selection Lenze
LCD
C0549 DFOUT_nOut_v g Digital frequency output DFOUT_IO_DigitalFrequency:
DFOUT_nOut_v as speed value (if C0540 = 1)
−32767 {1 rpm} 32767
C0559 SD8 Filter t 1.00 Filter time constant (SD8)
1 {1 ms} 200 Example:
When the setting is "10 ms", an SD8 TRIP is initiated after
10 ms.
C0575 max fld weak 4.00 Factor for limiting the max. possible field weakening
·
Setting "4.00" means, for example, max. 400 % field
weakening possible.
1.00 {0.01} 8.00
C0576 nErr Window 100 Tolerance margin for speed monitoring
·
Referred to n
max
.
·
100 % = lowest monitoring sensitivity.
0 {1 %} 100
C0577 Vp fld weak 3.00 Field weakening controller gain V
p
0.00 {0.01 ms} 15.99
C0578 Tn fld weak 10.0 Field weakening controller reset time Tn
2.0 {0.5 ms} 8192.0
8000 ms = switched off
C0579 MONIT nErr 3 Speed monitoring configuration
0 TRIP
1 Message
2 Warning
3 Off
4 FAIL−QSP
C0580 MONIT SD8 3 Monitoring configuration: Sin/cos encoder
0 TRIP
3 Off
·
Setting of the filter time constant (SD8) via C0559
C0581 MONIT Eer 0 Monitoring configuration: External error
0 TRIP
1 Message
2 Warning
3 Off
C0582 MONIT OH4 2 Monitoring configuration: Heatsink temperature
(Heatsink temperature > limit temperature C0122)
2 Warning
3 Off
C0583 MONIT OH3 à Monitoring configuration: Motor temperature
(Motor temperature > fixed limit temperature)
à Dependent on C0086
0 TRIP
3 Off
C0584 MONIT OH7 à Monitoring configuration: Motor temperature
(Motor temperature > variable limit temperature C0121)
à Dependent on C0086
·
Temperature monitoring via resolver input
2 Warning
3 Off
C0585 MONIT OH8 3 Monitoring configuration: Motor temperature
(Motor temperature across T1/T2 too high)
·
Temperature monitoring via PTC input
0 TRIP
2 Warning
3 Off
