9300 Servo PLC
Appendix
3.6
Code table
3−39
L
9300 Servo PLC EN 5.0
Code
Info
Possible settings
LCD
Code
Info
Selection
Lenze
LCD
C0470 FCODE 8bit
Freely configurable code (digital signals)
·
C0470 has the same memory address as C0471.
·
Hexadecimal value is bit−coded.
0
{hex}
FFFF
1
0
C0470/1 = C0471, bit 0 ... 7
2
0
C0470/2 = C0471, bit 8 ... 15
3
0
C0470/3 = C0471, bit 16 ... 23
4
0
C0470/4 = C0471, bit 24 ... 31
C0471 FCODE 32bit
0
Freely configurable code (digital signals)
·
Variables assigned via FCODE_FreeCodes:
FCODE_bC471Bit0_b ... FCODE_bC471Bit31_b
·
C0471 has the same memory address as C0470.
0
{1}
4294967296
C0472 FCODE analog
Freely configurable code (relative analog signals)
−199.99
{0.01 %}
199.99
1
0
FCODE_bC472_1_a
2
0
FCODE_bC472_2_a
3
100
FCODE_bC472_3_a
4
0
FCODE_bC472_4_a
...
...
...
20
0
FCODE_bC472_20_a
C0473 FCODE abs
Freely configurable code (absolute analog signals)
−32767
{1}
32767
1
1
FCODE_bC473_1_a
2
1
FCODE_bC473_2_a
3
0
FCODE_bC473_3_a
...
...
...
10
0
FCODE_bC473_10_a
C0474 FCODE PH
Freely configurable code (phase signals)
−2147483648
{1}
2147483647
1
0
FCODE_dnC474_1_p
...
...
...
5
0
FCODE_dnC474_5_p
C0475 FCODE DF
Freely configurable code (phase difference signals)
−16000
{1 rpm}
16000
1
0
FCODE_nC475_1_v
2
0
FCODE_nC475_2_v
