Commissioning
Actual values
Actual position
l
40
KHB 13.0004−EN 2.1
6.7
Actual values
6.7.1
Actual position
ƒ
Reading the actual position.
Due to the physical units, the resulting value may be higher than the maximum value
which can be represented by PNU 1100.
PNU
Name
Possible settings
Characteristics
Lenze
Selection
Description
1100
0 Position Actual
Value
{1 inc}
Ċ
INT32
RO
Ċ
Actual position value. The
value is scaled to the physical
unit set for PROFIBUS.
6.7.2
Actual speed value
ƒ
Reading the actual speed value.
PNU
Name
Possible settings
Characteristics
Lenze
Selection
Description
1101
0 Velocity Actual
Value
{1 rpm}
Ċ
INT32
RO
Ċ
Actual speed value. The value
is scaled to the physical unit
set for PROFIBUS.
6.7.3
Actual value of active current
ƒ
Reading the actual value of the active current.
PNU
Name
Possible settings
Characteristics
Lenze
Selection
Description
1102
0 Current Actual
Value
{1 }
Ċ
INT32
RO
Ċ
Actual value of active current.
The value refers to the rated
motor current.
