Lenze · E94AYCEP communication module (POWERLINK MN/CN) · Communication Manual · DMS 6.0 EN · 02/2014 · TD17
94
11
Parameter reference
11.2
Parameters of the communication module for slot MXI1
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C13238
C13239
C13240
Parameter | Name:
C13238 | EPL RPDO
Data type: UNSIGNED_64
Index: 11337 = 0x2C49
EPL index: See subcodes
EPL RPDO-8
Subcodes
Lenze setting
Info
EPL index
C13238/1
0
EPL RPDO
0x1607.0x01
...
...
...
...
C13238/32
0
EPL RPDO
0x1607.0x20
Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Parameter | Name:
C13239 | EPL RPDO
Data type: UNSIGNED_64
Index: 11336 = 0x2C48
EPL index: See subcodes
EPL RPDO-9
Subcodes
Lenze setting
Info
EPL index
C13239/1
0
EPL RPDO
0x1608.0x01
...
...
...
...
C13239/32
0
EPL RPDO
0x1608.0x20
Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Parameter | Name:
C13240 | EPL RPDO
Data type: UNSIGNED_64
Index: 11335 = 0x2C47
EPL index: See subcodes
EPL RPDO-10
Subcodes
Lenze setting
Info
EPL index
C13240/1
0
EPL RPDO
0x1609.0x01
...
...
...
...
C13240/32
0
EPL RPDO
0x1609.0x20
Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
