10
Error messages
10.1
Error messages of the communication module
63
Lenze · E94AYCEP communication module (POWERLINK MN/CN) · Communication Manual · DMS 6.0 EN · 02/2014 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
EPL: Internal watchdog activated [0x00c86011]
EPL: Internal error [0x00c86100]
EPL: Internal error [0x00c86101]
EPL: Invalid PDO mapping detected [0x00c86110]
EPL: Invalid parameter set [0x00c8641f]
EPL: Lenze setting loaded [0x00c86420]
Response (Lenze setting printed in bold)
Setting: not possible
None System fault Fault Trouble Quick stop by trouble Warning locked Warning Information
Cause
Remedy
Communication module is defective.
Send communication module together with a
description of the fault to Lenze.
Response (Lenze setting printed in bold)
Setting: not possible
None System fault Fault Trouble Quick stop by trouble Warning locked Warning Information
Cause
Remedy
Internal error.
Send communication module together with a
description of the fault to Lenze.
Response (Lenze setting printed in bold)
Setting: not possible
None System fault Fault Trouble Quick stop by trouble Warning locked Warning Information
Cause
Remedy
Internal error.
Send communication module together with a
description of the fault to Lenze.
Response (Lenze setting printed in bold)
Setting: not possible
None System fault Fault Trouble Quick stop by trouble Warning locked Warning Information
Cause
Remedy
The entered PDO mapping is invalid.
Re-execute PDO mapping.
Response (Lenze setting printed in bold)
Setting: not possible
None System fault Fault Trouble Quick stop by trouble Warning locked Warning Information
Cause
Remedy
No active parameter set could be loaded.
Download application again (including module).
Response (Lenze setting printed in bold)
Setting: not possible
None System fault Fault Trouble Quick stop by trouble Warning locked Warning Information
Cause
Remedy
Access via the Servo Drive 9400 to a parameter set in the
memory module failed.
Download application again (including module).
