C13062
C13063
Parameter | Name:
C13062 | EPL MN: boot timing
Data type: UNSIGNED_32
Index: 11513 = 0x2CF9
EPL index: See subcodes
The code defines timeouts and waiting times for the booting process of the Managing Node.
• The value "0" for subcode 2, 4, 5 deactivates the time-outs. The Managing Node waits for an indefinite period of
time. No error message is generated.
• The value "0" for subcode 3 deactivates the waiting time. After all expected Controlled Nodes have been detected
by the Managing Node, the Managing Node immediately changes to NMT_MS_PREOPERATIONAL_2.
Observe the following conditions:
• Subcode 1 must be lower than
- values of all EPL nodes.
• Subcode 3 must be lower than subcode 2.
Setting range
(min. value | unit | max. value)
0
μs
4294967295
Subcodes
Lenze setting
Info
EPL index
C13062/1
2500000 μs
Max. time for detecting a
redundant Managing Node
Waiting time before changing to
NMT_MS_PREOPERATIONAL_1
0x1F89.0x01
C13062/2
60000000 μs
Max. time for device search
Dwell time in
NMT_MS_PREOPERATIONAL_1
Error message if not all
Controlled Nodes are in
NMT_CS_PREOPERATIONAL_1.
0x1F89.0x02
C13062/3
0 μs
Waiting time in
NMT_MS_PREOPERATIONAL_1
0x1F89.0x03
C13062/4
0 μs
Max. time in
NMT_MS_PREOPERATIONAL_2
Error message if not all
Controlled Nodes are in
NMT_CS_PREOPERATIONAL_2.
0x1F89.0x04
C13062/5
0 μs
Max. time in
NMT_MS_READY_TO_OPERATE
Error message if not all
Controlled Nodes are in
NMT_CS_READY_TO_OPERATE.
0x1F89.0x05
Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Parameter | Name:
C13063 | EPL MN cycle timing
Data type: UNSIGNED_32
Index: 11512 = 0x2CF8
EPL index: See subcodes
The code defines time intervals for the cycle control by the Managing Node.
Setting range
(min. value | unit | max. value)
0
ns
4294967295
Subcodes
Lenze setting
Info
EPL index
C13063/1
2000 ns
Waiting time between SoC and
PReq
0x1F8A.0x01
C13063/2
750000 ns
Time-out SDO communication
0x1F8A.0x02
Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
