Page 75: 11 parameter reference

Lenze · E94AYCEP communication module (POWERLINK MN/CN) · Communication Manual · DMS 6.0 EN · 02/2014 · TD17
76
11
Parameter reference
11.2
Parameters of the communication module for slot MXI1
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C13030
C13034
C13035
Parameter | Name:
C13030 | EPL device type
Data type: UNSIGNED_32
Index: 11545 = 0x2D19
EPL index: 0x1000
The code indicates the device type of the EPL node.
Value is bit-coded:
Bit 1 Bit1
Bit 2 Bit2
Bit 3 Bit3
Bit 4 Bit4
Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Parameter | Name:
C13034 | EPL identity object
Data type: UNSIGNED_32
Index: 11541 = 0x2D15
EPL index: See subcodes
The code indicates the Manufacturer's EPL ID no. for Lenze.
Subcodes
Lenze setting
Info
EPL index
C13034/1
59
(0x3B)
Manufacturer's EPL ID no.
0x1018.0x01
Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
Parameter | Name:
C13035 | EPL device type CN
Data type: UNSIGNED_32
Index: 11540 = 0x2D14
EPL index: See subcodes
The code contains the device type ID of the declared Controlled Nodes. Each subcode corresponds to a Controlled
Node with the node ID = subcode number.
When being in the configured status, the values must be identical with the device types stored locally in each node
under
.
Subcodes
Lenze setting
Info
EPL index
C13035/1
0
EPL device type CN
0x1F84.0x01
...
...
...
...
C13035/100
0
EPL device type CN
0x1F84.0x64
Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
