ASSEMBLY INSTRUCTIONS
3-19
Figure 3-10: Hydraulic Fold Installation (2430-11-24 & 2430-13-24)
(E)
(B)
(F)
(N)
(J)
2430 fold hyd assembly op
(A-1)
(A-2)
(I)
FRONT
OF MACHINE
(B)
(C)
(D)
(I)
(J)
(K)
(L)
(M)
(N)
(O)
(P)
(E)
(F)
(G)
(H)
(A-2)
(A-1)
(A)
90 ELBOW W/ 1/16
RESTRICTOR
5 X 36 HYDRAULIC
CYLINDER
90 ADAPTER
3/8 X 82 HOSE
ASSEMBLY
1/2 X 251 HOSE
ASSEMBLY
STRAIGHT FITTING
1000 PSI RELIEF
VALVE
3/8 X 56 HOSE
ASSEMBLY
5 X 36 HYDRAULIC
CYLINDER
3/4-16 MALE
COUPLER
3/8 X 78 HOSE
ASSEMBLY
16 PORT
HYDRAULIC
MANIFOLD
90
ADAPTER
3/8 X 31 HOSE
ASSEMBLY
1/2 X 20 HOSE
ASSEMBLY
