Figure 3-6: depth stop assembly installation – Landoll 2430 Weatherproofer I User Manual
Page 32
3-12
F-652-0912 Edition
ASSEMBLY INSTRUCTIONS
Figure 3-6: Depth Stop Assembly Installation
2430 depth stop tube op
DEPTH STOP TUBE ASSEMBLY
DEPTH STOP
HANDLE
5/8-11 HEX LOCK NUT
DEPTH STOP MOUNT
PLATE
5/8-11 X 2-1/2 HEX
HEAD CAP SCREW
WHEEL AND LIFT
ASSEMBLY
FRAME ASSEMBLY
3/8-16 HEX
LOCK NUT
3/8-16 X 1-1/4
HEX HEAD
CAP SCREW
