ASSEMBLY INSTRUCTIONS
3-9
Wing and Extension Installation
(2430-11-24 & 2430-13-24)
IMPORTANT
Read all safety precautions at the front of the section
before attempting any of the following procedures.

WARNING
1. Assemble RH and LH wing assemblies to the main
frame assembly using hinge pin, 1-3/4 thrust washer,
1/2 x 2-1/4 grooved alloy pin, and 1-1/4 - 7 hex lock
nut (See Figure 3-4.)
NOTE
Thrust washers are located in between hinge ear plates
of wing.
2. Connect lock mount to hinge fold plates of wing
frame using lock mount, wing lock pin, 1-8 x 7 hex
head cap screw, wing lock spacer, and hex lock nut.
3. Connect rod end of 5 x 36 hydraulic cylinder to wing
through slots in the hinge fold plates using 1-1/4 x 7
pin, 1-1/4N flat washer, and 5/16 x 2-1/2 spring
slotted pin.
4. On 2430-13-24 models only, attach extension
weldment to RH and LH wing assemblies using
3/4-10 x 5-1/2 hex head cap screws and hex lock
nuts.
5. Add shank clamp assemblies to extension
weldments using shank clamp bolt and 1-8 hex lock
nut. See Figures 2-3 and 2-4 for shank placement
dimensions.
6. Tighten all hardware to the recommended torques
shown in Table 2-1.
7. Assemble the wheels and tires to the hubs. Tighten
wheel bolts evenly to assure proper wheel alignment.
Wheel bolts should be tightened to 450 ft. lbs.
(2430-11-24) or 90 ft-lbs. (2430-13-24) of torque. The
hoist can then be removed.
8. Inflate the tire as recommended by the manufacturer.
Do not attempt to lift heavy parts (such as the
frame, disc gangs, wheel lift, and pull hitch)
manually. Use a hoist or a forklift to move these
parts into position.
