Landoll 2430 Weatherproofer I User Manual
Page 28
3-8
F-652-0912 Edition
ASSEMBLY INSTRUCTIONS
Figure 3-4: Wing and Extension Installation (2430-11-24 & 2430-13-24)
MAIN FRAME
ASSEMBLY
5 X 36 HYDRAULIC
CYLINDER
5/16 X 2-1/2 SPRING
SLOTTED PIN
1-1/4N FLAT
WASHER
1-1/4 X 7 PIN
1-8 HEX LOCK NUT
SHANK CLAMP
ASSEMBLY
EXTENSION
WELDMENT
3/4-10 HEX
LOCK NUT
3/4-10 X 5-1/2 HEX
HEAD CAP SCREW
LH WING ASSEMBLY
RH WING ASSEMBLY
1-1/4 - 7 HEX
LOCK NUT
1-3/4 THRUST
WASHER
1/2 X 2-1/4 GROOVED
ALLOY PIN
HINGE PIN
WING LOCK
PIN
1/2 X 2 SPRING
SLOTTED PIN
1-8 X 7 HEX HEAD
CAP SCREW
LOCK MOUNT
WING LOCK
SPACER
2430_wing_inst
