Landoll 2430 Weatherproofer I User Manual
Page 34
3-14
F-652-0912 Edition
ASSEMBLY INSTRUCTIONS
Figure 3-7: Disc Gang Installation - Wings - 2430-11-24 & 2430-13-24
MAIN FRAME AND
WING ASSEMBLY
RIGHT REAR MAIN DISC
GANG ASSEMBLY
RIGHT REAR WING DISC
GANG ASSEMBLY
RIGHT FRONT
WING DISC GANG
ASSEMBLY
RIGHT FRONT
MAIN DISC GANG
ASSEMBLY
CLAMP PLATE
3/4-10 X 11 HEX
HEAD CAP
SCREW GR8
LEFT FRONT
MAIN DISC GANG
ASSEMBLY
3/8 WASHER
LEFT REAR MAIN DISC
GANG ASSEMBLY
LEFT REAR WING DISC
GANG ASSEMBLY
3/4-10 X 2 HEX HEAD
CAP SCREW GR8
LEFT FRONT WING DISC
GANG ASSEMBLY
3/4-10 HEX LOCK NUT
2430 disc gang inst
3/4W FLAT
WASHER
3/4-10 X 2-1/4 HEX
HEAD CAP SCREW
3/4-10 X 11
HEX HEAD
CAP SCREW
DETAIL A
SEE DETAIL
A
