Landoll 2430 Weatherproofer I - Manual (Page 23)

ASSEMBLY INSTRUCTIONS
3-3
Weatherproofer I Main Frame
Assembly
IMPORTANT
Read all safety precautions at the front of the section
before attempting any of the following procedures.

WARNING
1. Place both frame halves on stands approximately 36”
high. The assembly area should be a large level area
of sufficient size to accommodate the
Weatherproofer I when fully assembled.
2. Bolt frame halves together using 3/4-10 x 2-1/4 hex
head cap screws and hex lock nuts. Leave all screws
loose.
3. Attach front fold anchor plate to the main frame
assembly using 3/4-10 x 6 hex head cap screws.
4. Slide wing fold spacer tubes together at slot.
5. Attach wing fold spacer tubes to the front fold anchor
plate using 3/4-10 x 6 hex head cap screws.
6. Lift rear fold anchor plate and place over 3/4-10 x 6
hex head cap screws that are connecting the front
rear anchor plate to the frame assembly.
7. Place 3/4-10 hex lock nuts onto each screw. Leave
all screws loose.
8. Attach base end of each 5 x 36 hydraulic cylinders to
top of front and rear fold anchor plates using cylinder
mount plates, pivot bushings, 3/4-10 x 6 hex head
cap screws, and hex lock nuts.
9. Attach rear wing rest plate to rear of frame assembly
using 5/8-11 x 5-1/2 hex head cap screws.
10. Attach wing rest tube to top of rear wing rest plate
using 5/8-11 x 5-1/2 hex head cap screws.
11. Attach front wing rest plate top rear wing rest plate
over 5/8-11 x 5-1/2 hex head cap screws that are
holding the rear wing rest plate and wing rest tube in
place. Place 5/8-11 hex lock nuts onto each screw.
Leave all screws loose.
12. Level the frame halves.
13. Tighten all hardware to the recommended torques
shown in Table 2-2.
Do not attempt to lift heavy parts (such as the
frame, disc gangs, wheel lift, and pull hitch)
manually. Use a hoist or a forklift to move these
parts into position.
