Figure 3-1: main frame assembly – Landoll 2430 Weatherproofer I User Manual
Page 22
3-2
F-652-0912 Edition
ASSEMBLY INSTRUCTIONS
Figure 3-1: Main Frame Assembly
main frame inst
WING FOLD SPACER
TUBE
PIVOT BUSHING
CYLINDER MOUNT
PLATE
FOLD ANCHOR
PLATE
3/4-10 X 6 HEX
HEAD CAP SCREW
3/4-10 HEX LOCK NUT
RH MAIN FRAME
WELDMENT
3/4-10 HEX
LOCK NUT
3/4-10 X 2-1/4 HEX
HEAD CAP SCREW
5 X 36 HYDRAULIC
CYLINDER
1-1/4N FLAT WASHER
5/16 X 2-1/2 SPRING
SLOTTED PIN
1-1/4 X 7 PIN
WING REST
PLATE
WING REST
TUBE
5/8-11
LOCK
NUT
LH FRAME WELDMENT
HEX
5/8-11 X 5-1/2 HEX
HEAD CAP SCREW
