6.3.8.2
Configuring analog outputs
You can determine how the voltage of the analog outputs is set.
1 Select "
> Set up > Interfaces > I/O Module > Analog Outputs".
2 For "Config. Analog Output 1" or "Config. Analog Output 2" choose between:
– Set by interface
– Leakage rate linear
– Off
6.3.8.3
Setting the upper scale value for 10 V of the analog output
You can set which leakage rates are represented by 10 V on the analog output. This setting
only comes into effect when "leakage rate linear" is selected for the configuration of the
analog output.
1 Select "
> Set up > Interfaces > I/O Module > Analog Scale".
2 To set the upper scale value, enter a numerical value between, for example, 10 g/a and
1000 g/a using the keys.
6.3.8.4
Setting up the I/O module protocol
Refer to "Interface description HLD6000 (doc. no. kins44e1-a)" for switching between
"ASCII", "LD" (Leak Detection), "Normal" and "Simple" formats.
1 Select "
> Set up > Interfaces > I/O Module > Protocol".
2 Select between "ASCII", "LD", "Normal", and "Simple".
6.3.8.5
Configuring PLC outputs
You can set which function should be displayed on the PLC output.
1 Select "
> Set up > Interfaces > I/O Module > PLC Outputs".
2 Select one of the 8 PLC outputs and allocate a function to it:
– Setpoint 1 or 2
– CAL internal active
– CAL external active
– PROOF active
– Warning
– Error
– CAL or PROOF active
– CAL request
– Run up
– Sniffer button
– Light barrier
– Measuring
– Standby
– Sniffer is closed
– Error or warning
– CAL internal possible
