steps for updating.
The first screen of the RDM wizard will display all Net3 Two Port and Four Port Gateways in a
selection tree.
Under each Gateway’s name there will be checkboxes for each of the Gateway’s ports. The
checkboxes are labeled by port number and show the current mode. Ports in output or download
modes will be checked by default, and ports in input or disabled modes will be unchecked by
default.
To select all ports on all gateways, you can use the {Check All} button. To clear your selection,
use {UnCheck All}.
Press {Begin Update} at the bottom of the page to start the update process for devices connected
to the selected ports.
The RDM Wizard will display an update progress screen, which shows progress bars for each port
N o t e : Only Gateways that are running version 5.1 or later will be displayed in the
selection tree.
