Change chasers and holders – ERICO LENTON Mid-Range Bar Threader User Manual
Page 13
www.erico.com
13
Before replacing the holders make sure the cavity in the head and the holders are clear and free of chips.
Wipe all flat surfaces with a clean rag.
The number 1 holder with the slot in it to accept the
control block must be replaced first, followed by
holders 4, 2 and 3.
Step 1 – insert holder #1 as shown.
Step 2 – Slide holder #4 into position
Step 3 – Slide holder #2 into position
Change Chasers and Holders
10A
10B
11A
11B
11C
11D
