Electrical Specifications

Ground Resistance

Measurement

Range

Resolution

Accuracy*

Range

0.1 to 1.00Ω

0.01Ω

± (2% R ± 0.02Ω)

1.0 to 50.0Ω

0.1Ω

± (1.5% R ± 0.1Ω)

Autoranging

50.0 to 100.0Ω

0.5Ω

± (2.0% R ± 0.5Ω)

0.01Ω to 1200Ω

100 to 200Ω

± (3.0% R ± 1Ω)

200 to 400Ω

± (6.0% R ± 5Ω)

400 to 600Ω

10Ω

± (10% R ± 10Ω)

600 to 1200Ω

50Ω

Approx. 25% ± 50Ω

Ground or Leakage Current

Measurement

Range

Resolution

Accuracy*

Range

Autoranging

1 to 299mA

1mA

± (2.5% R + 2mA)

1mA to 30.00A rms

0.300A to 2.999A

0.001A

± (2.5% R + 2mA)

3.00A to 29.99A

0.01A

± (2.5% R + 20mA)

R = Reading

* Reference conditions: 23°C ± 3K, 50% RH ± 10%, battery at 8V ± 0.2V, external

magnetic field < 40A/m, external electrical field < 1V/m, conductor centered, loop
resistance noninductive. Accuracy % of Reading, Frequency: 50/60Hz.

Resistance Measurement Frequency: 2403Hz

Voltage Generated into the Loop: Approx. 60mV rms

Resistance Overload: OL displayed above 1200Ω

Current Measurement Frequency: 47 to 800Hz

Influence of Frequency: Add 7.5% to the reference specification

Current Overload: OL displayed above 29.99A rms
