Function Controls
Current
Press A to enter the current function. True RMS
current measurements are possible up to 30.00A
(Fig. 11).
Above 30A rms, OL will be displayed and the test
must be discontinued. The beeper is also activated
during OL.
Range
Resolution
1 to 299mA
1mA
0.300 to 2.999A
0.001A (1mA)
3.00A to 29.99A
0.01A (10mA)
Function Access Summary
Function
Push Button(s)
Function Setting
Used
Saved @ Power Down
On/Off
ON/OFF
Ω Function
Ω
Default Setting
A Function
A
No
Display Hold
HOLD
No
Auto-Off On/Off
ON + HOLD
No
Beeper On/Off
ON + Ω
No
Figure 11
