DC Whistle Installation Guide

MAN-DCWHIIG (Ver. 1.101)

www.elmomc.com

50

Chapter 4:

Technical Specifications

This chapter provides detailed technical information regarding the DC Whistle. This includes its
dimensions, power ratings, the environmental conditions under which it can be used, the
standards to which it complies and other specifications.

4.1. Features

The DC Whistle’s features determine how it controls motion, as well as how it processes host
commands, feedback and other input.

Operating power

DC power supply: 11 to 95 VDC source

DC BUS

DC power supply

Control supply

A separate DC power supply 11 to 95 VDC serves as both the auxiliary supply and

the backup supply (Option)

Operating modes

Current, velocity and position

Commutation alternatives

Sinusoidal vector control

Trapezoidal

DC brush

Feedback alternatives

Incremental encoder + digital Halls

Incremental encoder only

Digital Halls

Resolver

Sin / Cos

Sin / Cos + Digital Halls

Analog Halls

Tachometer

Potentiometer

Communication

Simultaneous operation of RS-232 and CAN DS 402 User programming

User Programming

Third-generation programming environment (language and Elmo Studio)
