DC Whistle Installation Guide

MAN-DCWHIIG (Ver. 1.101)

www.elmomc.com

15

Chapter 3:

Installation

The DC Whistle must be installed in a suitable environment and properly connected to its
voltage supplies and the motor.

3.1. Site Requirements

You can guarantee the safe operation of the DC Whistle by ensuring that it is installed in an
appropriate environment.

Feature

Value

Ambient operating temperature

0 °C to 40 °C (32 °F to 104 °F)

Maximum operating altitude

2,000 m (6562 feet)

Maximum relative humidity

90% non-condensing

Operating area atmosphere

No flammable gases or vapors permitted in area

Models for extended environmental conditions are available.

Caution:
The Whistle on the DC Whistle dissipates its heat by convection. The
maximum operating ambient temperature of 0 °C to 40 °C (32 °F to 104 °F)
must not be exceeded. Refer to the Heat Dissipation section of the
Whistle/Tweeter Installation Guide for more information.

3.2. Unpacking the Drive Components

Before you begin working with the DC Whistle, verify that you have all of its components, as
follows:

The DC Whistle.

The Composer software and software manual.

The DC Whistle is shipped in a cardboard box with Styrofoam protection.
To unpack the DC Whistle:

Carefully remove the DC Whistle from the box and the Styrofoam.
Check the DC Whistle to ensure that there is no visible damage to the instrument. If any

damage has occurred, report it immediately to the carrier that delivered your DC Whistle.

To ensure that the DC Whistle you have unpacked is the appropriate type for your

requirements, locate the part number sticker on the side of the DC Whistle. It looks like
this:
