2.4. How to Use this Guide
In order to install and operate your Elmo DC Whistle, you will use this manual in conjunction
with a set of Elmo documentation. Installation is your first step; after carefully reading the
safety instructions in the first chapter, the following chapters provide you with installation
instructions as follows:
•
Chapter 3, Installation
, provides step-by-step instructions for unpacking, mounting,
connecting and powering up the DC Whistle.
•
Chapters 4 and 5
list all the drive ratings and specifications as well as information on the
relevant cables.
Upon completing the instructions in this guide, your DC Whistle should be successfully
mounted and installed. From this stage, you need to consult higher-level Elmo documentation
in order to set up and fine-tune the system for optimal operation:
•
The Composer Software Manual, which includes explanations of all the software tools that
are part of Elmo’s Composer software environment
•
The SimplIQ Command Reference Manual, which describes, in detail, each software
command used to manipulate the DC Whistle motion controllers
•
The SimplIQ Software Manual, which describes the comprehensive software used with the
DC Whistle
