1.5.2. Dimensions
Models
Chamber Size
inches (cm)
Capacity
ft
3
(liters)
Overall Size
inches (cm)
Maximum
number of
Shelves
W
*
D
H
W
D
H
LCC/LCD2-14
25.5
(64)
26
(66)
37
(94)
14
(396)
47.5
(121)
41.5
(105)
71
(180)
11
The LCC/LCD2-14 oven is not intended to process solvents or other
volatile or flammable materials. Oven forced exhaust is intended for
cooling purposes only on standard and inert (nitrogen) models.
Order an LCC/LCD2-14 oven with the Class A option to process
solvents or other volatile or flammable materials.
1.5.3. Capacities
Models
LCC/LCD2-14
Maximum Load
(Lbs)
(KG)
400
181
Maximum Shelf Capacity
(Lbs)
(KG)
50
23
Recirculating fan
(CFM/LPS)
950/448
(H.P.)
1.5
Net weight (Approximate)
(Lbs)
955
(KG)
434
Shipping weight (Approximate)
(Lbs)
1050
(KG)
477
Exhaust fan
(CFM/LPS)
(HP)
85/40
0.03
Exhaust Opening Diameter
(Inch)
4
(mm)
101.6
*
Clear opening width is reduced by 1.5 inches (3.8cm) due to ¾ inch (1.9cm) shelf supports on each side.
