LCC/LCD2-14 Series Oven
Owner’s Manual
10
Version 1
Copyright © 2013 by Despatch Industries.
All rights reserved. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any
means including graphic, electronic, or mechanical methods or photocopying, recording, or information storage and
retrieval systems without the written permission of Despatch Industries, unless for purchaser's personal use.
1.5.4. Power
If the line voltage for your LCC/LCD2-14 Series oven varies more than 10% from the oven
voltage rating, electrical components such as relays and temperature controls may operate
erratically. Power connection is performed by the user.
If the line voltage is lower than the oven voltage rating, heat-up time may be significantly
longer and motors may overload or run hot
If the line voltage is higher than the nameplate rating, motors may run hot and draw excessive
amperage
Table 2. Electrical Specifications.
Models
Volts
Amps
Phase
Hertz
Heater (kW)
LCC/LCD2-14
208
50.5
3
50/60
16
240
44.5
3
50/60
16
380
21.6
3
50
12
415
25.2
3
50
16
480
22.2
3
60
16
1.5.5. Temperature
Model
LCC/LCD2-14
Time to Temperature
(approximate
minutes)
(no load)
50°C
– 100°C
3 min.
50°C
– 200°C
9 min.
50°C
– 260°C
15 min.
50°C
– 350°C
†
35 min.
Cooling Time to Temp
Minutes
(No Load)
‡§
100°C
– 65°C
41 min. (air atmos.)
15 min. (nitrogen atmos.)
175°C
– 65°C
82 min. (air atmos.)
20 min. (nitrogen atmos.)
260°C
– 65°C
95 min. (air atmos.)
25 min. (nitrogen atmos.)
350°C
– 65°C
116 min. (air atmos.)
30 min. (nitrogen atmos.)
Temperature
Uniformity at
**
100°C
±1°C
175°C
±2°C
260°C
±3°C
350°C
±3.5°C
Maximum Operating
Temperature
LCC
260°C
†
For LCD only, LCC maximum temperature: 260°C.
‡
Minimum operating temperatures and cooling times are based on a 20°C ambient temperature measured at
the fresh air inlet.
§
Based on cooling water supplied at 3 GPM (11 lpm), 13°C (55°F).
**
Uniformity figures are based on a nine-point test conducted in an empty oven after stabilization period.
Uniformity can vary slightly depending on unit and operating conditions. Class 100 HEPA filtration will
limit ramp rates. Specifications are subject to change without notice.
