4.2.1.1. Oven Placement Requirements

The LCC/LCD2-14 Series oven has a four inch diameter exhaust opening.

The oven may be placed next to another cabinet on its right, or next to another oven, with
three-quarters of an inch (19mm) clearance (measure with door open).

Exhaust air may reach 260°C on the LCC version and 350°C on the LCD version. Make sure
exhaust piping materials can withstand these temperatures.

LCC/LCD2-14 oven exhaust opening is on the rear of the oven.

Plumb and level the oven to assure proper heat distribution and operation of all mechanical
components.

Leave room at the oven sides and rear for maintenance.

The rear of the oven may be placed against a wall (with proper spacing).
4.2.2. Oven Utility Connections
Utility connections vary slightly on different LCC/LCD models. Table 3 lists the connection
purposes and parameters. Refer to Figure 8 for a visual reference.
Table 3. Utility Connections (Refer to Figure 8).
Connection
LCC/LCD Air Atmosphere models
with optional water-cooling LCC/LCD Nitrogen Atmosphere
models with standard water-cooling
NITROGEN
INLET 
Clean Dry Air Inlet (70-80 psi
(4.83-5.52 bar))

Used to purge water from coil
prior to heating oven
 3/8” NPT female brass
connections provided

Nitrogen Inlet (70-80 psi (4.83-5.52
bar))

Purge nitrogen, clean dry air and
water from coil prior to heating the
oven
 3/8” NPT female brass connections
provided
WATER
OUTLET 
During cooling cycle, water flows through the water coil and out this
connection
 3/8” NPT female brass connections provided

Piping must be rated for up to125°C (257°F)
Warning!
Do not use the oven in wet, corrosive or explosive atmospheres
unless this oven is specifically designed for a special
atmosphere.

The rear of a LCC/LCD2-14 Series Class A oven must have a minimum
of six inches of clearance between the oven and any wall for explosion
relief.
