A PPENDICES LCC/LCD2-14 Series Oven Owner’s Manual
52 Version 1
Copyright © 2013 by Despatch Industries.
All rights reserved. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any
means including graphic, electronic, or mechanical methods or photocopying, recording, or information storage and
retrieval systems without the written permission of Despatch Industries, unless for purchaser's personal use.
8.2. LCC/LCD2-14 Series Oven Options
8.2.1. Optional MRC5000 Setup

Refer to instructions provided recorder manufacturer for more
specific installation notes.
Temperature is retransmitted to the MRC5000 recorder from the controller. To set up the
recorder:
1. Ensure hardware jumper JU1 is in place for the 5 VDC setting (Refer to MRC5000 Manual
included).
2. Move MODE to PROG/TEST/CAL to display Prog .
3. Press ▼ twice to display Inps
. Move to each Parameter Code using ▼or ▲. Adjust each
Parameter Code using the settings in Table 7.
4. After adjusting all settings, move MODE to RUN . Display on both the recorder and controller
should read the same.
Table 7. MRC 5000 Settings.
Parameter Code
Degrees C Degrees F
Inps 18 18
Icor 0 0
diSP On On
dPOS 0 0
EUU
6
400 752
EUL 6 0 32
ChUP 400 800
7
ChLO 0 0
DFF 1 1
8.2.2. Optional High Limit Alarm with Alarm Silence
The LCC/LCD2-14 Series oven optional High Limit Alarm provides an audible and visual alarm
when the temperature exceeds the High Limit setpoint on the control. The alarm horn is typically
located to the right of the control panel door.
6
These values must match the settings RetOutLo and RetOutHi on the Protocol 3 Control page. For
example, if RetOutLo is 32, EUL must read 32.
7 Change 0-400 chart paper to 0-800 chart paper. Depending on the equipment used, 0-600 paper may be
used if the maximum temperature is 500°F.
