T HEORY OF O PERATION LCC/LCD2-14 Series Oven Owner’s Manual
22 Version 1
Copyright © 2013 by Despatch Industries.
All rights reserved. No part of the contents of this manual may be reproduced, copied or transmitted in any form or by any
means including graphic, electronic, or mechanical methods or photocopying, recording, or information storage and
retrieval systems without the written permission of Despatch Industries, unless for purchaser's personal use.
3.4. Optional Beacon Light
The LCC/LCD2-14 Series beacon light option provides
visual cycle process indication to the operator (Figure 7).
The beacon light option is on the front control panel of both
the LCC/LCD2-14PT-3 Pass-Through oven and the standard
LCC/LCD2-14 oven.
The beacon light provides visual indication of the cycle status
as follows:

Green: Cycle in process

Yellow: Standby. Operator has unloaded product. Oven waiting for next cycle.

Red: Error or fault condition.
Figure 7. LCC/LCD2-14 Series Optional
Beacon Light.
