a. The oven should be idle, empty, with the door closed and awaiting the next lot for

processing.

b. The Protocol 3 Controller should not be running a profile.

2. Open the oven door.



The amber beacon light (

Error! Reference source not found.

)

ill be ON (steady) until the profile is started (at the completion of
Step 5).

3. Place the product on the shelf in the oven.
4. Close the oven door.
5. Run the desired profile with the Protocol 3 Controller.

a. Press

Select

until

Profile

is displayed.

b. Press

▲

▼

to display the desired profile.

c. Press

Run

to start the Profile Mode.



After pressing Run, the display changes from Stop to Run.
Segment time remaining and Current Segment number will
display.

6. At this point, the oven profile cycle is in process and the door is locked.

a. The green beacon light is ON (steady), the amber beacon light is off.
b. When the process is complete, the amber beacon should be ON, and the door is

unlocked.

7. Close the oven door to complete the process cycle. The oven is ready for the next lot.



Press Run at any time to active the Profile Mode.
