Upgrading The Computer
6 - 10 Upgrading the Optical (CD/DVD) Device
6
Removing the Optical Device for Model B & C Computers
1. Turn off the computer, and turn it over and remove the battery.
2. Remove the hard disk (see page 6 - 4 )
3. Remove the screw at point , and use a screwdriver to carefully push out the
optical device at point .
4. Reverse the process to install the new device.
Figure 6 - 6
Removing the
Optical DVD
Device
(Model B & C
Computers)
1
2
1
2
2
2
1
Model C
Model C
Model B
Model B
2
