CH-66, I-66, MD-66 - Drain Assembly
1 100036 TEE, 1-1/2" NPT GALVANIZED 2
2 100043 NIPPLE, 1-1/2" NPT X CLOSE, GALVANIZED 2
3 100140 HEX PLAIN NUT 3/8-16, SST 4
4 100587 PLUG, 1-1/2" NPT, SQ. HEAD, GALV. 1
5 100589 UNION, 1-1/2" NPT GALVANIZED 1
6 100735 BOLT, HEX HD., 1/4-20 X 5/8" SST 4
7 100736 BOLT, HEX HD., 1/4-20 X 3/4" SST 8
8 101830 NIPPLE, 1-1/2" NPT X 2" LG. GALV. 1
9 101833 NIPPLE, 1-1/2" NPT X 2-1/2" LG. GALV. 1
10 102376 WASHER, FLAT 5/16" SST 8
11 102563 BOLT, HEX HEAD, 3/8-16 X 3/4" SST 4
12 104165 CLAMP, HOSE M40 SST GEAR-TYPE 2
13 106407 WASHER, LOCK 3/8" SPLIT SST 4
14 106482 WASHER, LOCK 1/4" SPLIT SST 12
15 107340 CLAMP, HOSE M28 SST GEAR-TYPE 2
16 108345 GASKET 2
17 111034 DRAIN BODY, MACHINED 2
18 111113 NIPPLE TOE, 1-1/4" NPT X 2" LG. GALV. 1
19 114185 GRIP, DRAIN HANDLE 2
20 114216 TEE, 1-1/2" NPT X 1-1/2" NPT X 1-1/4" NPT, GALV. 1
21 114718 VALVE, BALL 1-1/2" UNION END WITH TEE HANDLE 2
22 114817 SLEEVE BEARING, 1/2" DIA. ROD NYLON 2
23 202438 HOSE, 1.625" ID X 12" LG. 1
24 206430 NIPPLE TOE, 1-1/2" NPT X 6" LG. GALV. 2
25 202438 HOSE, 1.875" ID X 23" LG. 1
26 304816 STRAINER, DRAIN 2
27 333268 DRAIN HANDLE WELDMENT 2
28 333511 BRACKET, DRAIN LEVER SUPPORT MT-RACK 2
--- 601950 PIPING ASSY, DRAIN (PREWASH) 1
(INCLUDES ITEMS 1, 2, 5, 8, 9, 17-21, 27)
--- 602031 PIPING ASSY, DRAIN (WASH) 1
(INCLUDES ITEMS 1, 2, 4, 17, 19, 21, 27)
NS 114825 NAMEPLATE, DRAIN, MD-RACK 2
71
Item
No. Part No. Description Qty.
