All Models - Control Cabinet
1
113936
LABEL, TABLE LIMIT SWITCH/ MACHINE RUN
1
2
107171
TERMINAL BLOCK, 4-POLE
1
3
111153
FUSE BLOCK, 600V 30A
2
4
112482
FUSE, 3.5A, LPCC 200-220-230-240/60/3
2
---
114797
FUSE, 2.0A, LPCC 460-480/60/3
2
5
108122
CONTACTOR, MTR. 12A (Qty. 2 for MD44, Qty. 3 for MD66)
A/R
6
111624
OVERLOAD, MTR. 200-220-230-240/60/3 (0.63-1.0A) Drive
1
---
111623
OVERLOAD, MTR. 460-480/60/3 (0.4-.63A) Drive
1
7
111629
OVERLOAD, MTR. 200-220-230-240/60/3 (6-10A) Prewash MD66
1
---
111627
OVERLOAD, MTR. 460-480/60/3 (2.5-4.0A) Prewash MD66
1
8
111629
OVERLOAD, MTR. 200-220-230-240/60/3 (6-10A) Wash
1
---
111627
OVERLOAD, MTR. 460-480/60/3 (2.5-4.0A) Wash
1
9
103310
LUG, GROUND
1
10
111833
BLOCK, TERMINAL 175A, 3-POLE
1
11
111827
CONTACTOR, HEAT 60A (Qty. 2 for 40°Rise, Qty. 3 for 70°)
A/R
12
180171
FUSE BLOCK, 600V/60A 200-220-230-240-460-480V WASH
1
13
180171
FUSE BLOCK 600V/60A 3P J-TYPE FOR 40°RISE BOOSTER
1
---
108424
FUSE BLOCK 600V/100A 3P T-TYPE FOR 70° RISE BOOSTER
1
14
0503749
TERMINAL BLOCK, 11-POLE
1
15
111068
RELAY, 2 POLE 120V
1
16
100294
TERMINAL BLOCK, 6-POLE
1
17
114760
LABEL, DETERGENT/RINSE AID/VENT FAN
1
18
109064
TRANSFORMER, 250VA 200-220-230-240-460-480:120V
1
19
114756
RACK CONTROL MODULE
1
20
114759
SUPPPORT, PCB
4
21
111633
BUS SYSTEM (2-UNIT) FOR CH44,MD44
1
---
111671
BUS SYSTEM (3-UNIT) FOR CH66, MD66
1
22
180175
FUSE, 600V/50A J-TYPE 200-220V/50-60/3
3
---
180174
FUSE, 600V/45A J-TYPE 230-240/50-60/3
3
---
180243
FUSE, 600V/25A J-TYPE 460-480/60/3
3
23
180176
FUSE, 600V/60A J-TYPE 200-220V/50-60/3 40°Rise Booster
3
---
180175
FUSE, 600V/50A J-TYPE 230-240V/50-60/3 40°Rise Booster
3
---
180243
FUSE, 600V/25A J-TYPE 460-480V/60/3 40°Rise Booster
3
---
108448
FUSE, 600V/90A T-TYPE 200-220V/50-60/3 70°Rise Booster
3
---
180059
FUSE, 600V/80A T-TYPE 230-240V/50-60/3 70°Rise Booster
3
---
180173
FUSE, 600V/40A J-TYPE 460-480V/60/3 70°Rise Booster
3
24
114771
WIRE HARNESS, MOLEX 8-PIN INPUT
1
25
114769
WIRE HARNESS, MOLEX 6-PIN INPUT
1
26
114770
WIRE HARNESS, MOLEX 6-PIN OUTPUT
1
27
114772
WIRE HARNESS, MOLEX 6-PIN OUTPUT HEAT
1
35
Item
No.
Part No.
Description
Qty.
