CHAMPION CH66 Manual - Manual (Page 61)

All Models - Wash Spray Arms
1 334979 FLANGE WELDMENT, LOWER WASH 1
2 100734 BOLT, HEX HEAD, 1/4-20 X 1/2" SST 4
3 100735 BOLT, HEX HEAD, 1/4-20 X 5/8" SST 4
4 102376 WASHER, FLAT 5/16" SST 8
5 104618 WASHER, FLAT 3/8" SST 8
6 106013 WASHER, LOCK 5/16" SPLIT SST 8
7 106014 HEX ACORN PLAIN NUT, 1/4-20 SST 16
8 106026 WASHER, FLAT 1/4" SST 8
9 106482 WASHER, LOCK 1/4" SPLIT SST 4
10 108345 GASKET, HEATER/STANDPIPE 2
11 109009 HEX GRIP NUT, 5/16-18 SST W/NYLON 8
12 111532 O-RING 2
13 113555 THREADED PLUG, WASH ARM 16
14 113716 WASH-ARMS O-RING 16
15 333096 STANDPIPE WELDMENT 44" MT-RACK 1
16 417963-S MANIFOLD TAPER ASSEMBLY, UPPER 1
17 333102 MANIFOLD TAPER ASSEMBLY, LOWER 1
18 333105 UPPER WASH SUPPORT ROD WELDMENT, MT-RACK 2
19 333460 FLANGE WELDMENT, WASH SYS. CONN. MT-RACK 2
20 333566 BRACKET, UPPER WASH ADJUSTMENT MT-RACK 2
21 334977 BRACKET, LOWER WASH, LATCH 2
53
Item
No. Part No. Description Qty.
