CHAMPION CH66 Manual - Manual (Page 59)

CH-66, I-66, MD-66 - Prewash Spray Arms
1 100154 HEX PLAIN NUT, 5/16-18 SST 4
2 100734 BOLT, HEX HEAD, 1/4-20 X 1/2" SST 4
3 102376 WASHER, FLAT 5/16" SST 4
4 106026 WASHER, FLAT 1/4" SST 4
5 106013 WASHER, LOCK 5/16" SST 4
6 106014 HEX ACORN PLAIN NUT, 1/4-20 SST 4
7 106482 WASHER, LOCK 1/4" SPLIT SST 4
8 108345 GASKET, HEATER/STANDPIPE 2
9 111532 O-RING 1
10 333105 UPPER WASH SUPPORT ROD WELDMENT, MT-RACK 2
11 333460 FLANGE WELDMENT, WASH SYS. CONN. MT-RACK 1
12 333566 BRACKET, UPPER WASH ADJUSTMENT MT-RACK 2
13 418238-S MANIFOLD TAPER ASSY. UPPER WASH 1
14 333712 STANDPIPE WELDMENT, 1-1/4" OD MD66 1
51
Item
No. Part No. Description Qty.
