CHAMPION CH66 Manual - Manual (Page 49)

All Models - Wash Tank Heat, Float Switch, and Scrap Screens
1 100154 HEX PLAIN NUT, 5/16-18 SST 4
2 100547 LOCKNUT, 1/2" NPT SST 3
3 100740 BOLT, HEX HD., 5/16-18 X 1" SST 4
4 102376 WASHER, FLAT 5/16", SST 8
5 104882 WASHER, FLAT SST 1
6 106013 WASHER, LOCK 5/16" SPLIT 4
7 107089 HEX PLAIN JAM NUT, 1/2-13 SST 1
8 107589 WASHER, LOCK 1/2" SPLIT SST 1
9 108345 GASKET, HEATER 1
10 109069 THERMOSTAT, CONTROL WITH CAPILLARY 2
11 110561 THERMOSTAT, HIGH LIMIT WITH CAPILLARY 2
12 113291 FLOAT SWITCH 1
--- 111151 C-CLIP 4
13 113516 HEATER, 15/18.1kW 200-220V/50-60/1 & 3PH 1
380V/50-60/3
--- 113517 HEATER, 15/16.3kW 230-240V/50-60/1 & 3PH 1
400-415V/50-60/3
--- 113518 HEATER, 15/16.3kW 460-480V/60/3 1
14 201041 WASHER, SPACER 3
15 323430 BRACKET, THERMOSTAT 1
16 107440 THERMOMETER, 8 FT. FLANGED 1
17 108418 PLUG, 1/2" NPT PLASTIC 1
18 108417 NUT, 1/2" NPT PLASTIC 1
19 109034 GASKET, 1/2" PLUG 1
20 305163 SCREEN SUPPORT WELDMENT 1
21 333078 FILLER, SCREEN 2
22 305164 SCREEN, SCRAP WELDMENT 4
23 100097 SCREW, 10-32 X 1/2" TRUSS HD. 2
24 107966 NUT, GRIP 10-32 W/NYLON INSERT 2
25 106014 NUT, ACORN 1/4-20 6
26 106482 WASHER, LOCK 1/4" SPLIT 6
27 106026 WASHER, FLAT 1/4" 6
28 100141 NUT, GRIP 1/4-20 SST 2
29 333088 ENCLOSURE WELDMENT, 3.25" X 12" X 16" 1
41
Item
No. Part No. Description Qty.
