CHAMPION CH66 Manual - Manual (Page 67)

All Models - Drive Motor Assembly
1 0509199 DRIVE MOTOR SWITCH 1
2 327918 BRACKET, MOTOR SWITCH MOUNTING 1
3 113893 SHEAVE, MOTOR AK51, 5/8" BORE 1
4 327916 PLATE, DRIVE MOTOR TORQUE 1
5 327920 BRACKET, 44 MOTOR ASSY. MOUNTING 1
6 327919 BRACKET, MOTOR SPRING MOUNTING 1
7 106482 WASHER, LOCK 1/4" SPLIT SST 4
8 102376 WASHER, FLAT 5/16" SST 2
9 113702 SPRING, 0.06" OD X 0.095" WIRE X 1.5" LG. 1
10 113704 BOLT, HEX HEAD, 5/16-18 X 3-1/2" 1
11 113701 BUSHING, FLANGE 1/4" X 3/8" X 1/4" LG. BRONZE OIL 1
12 113703 BUSHING, FLANGE 5/8" X 7/8" X 3/8" X 1-1/8" LG. BRONZE OIL 1
13 113700 BUSHING, THRUST 3/8" X 3.4" X 1/16" BRONZE OIL 3
14 113732 MOTOR, GEAR 1/6 HP, 3PH, MV 1
--- 113679 MOTOR, GEAR 1/6 HP 1PH, MV 1
15 100734 BOLT, HEX HEAD 1/4-20 X 1/2" SST 4
16 100736 BOLT, HEX HEAD 1/4-20 X 3/4" SST 3
17 109009 NUT, GRIP 5/16-18 W/NYLON INSERT 1
59
Item
No. Part No. Description Qty.
Item
No. Part No. Description Qty.
International Models I-44, I-66 Drive Motors
14 113679 MOTOR, GEAR 1/6 HP, 1PH, MV 1
200-220/50-60/1PH, 230-240/50-60/1PH
--- 113732 MOTOR, GEAR 1/6 HP, 1PH, MV 1
200-220/50-60/3PH, 230-240/50-60/3PH
380/50-60/3, 400-415/50-60/3
