CH-44, I-44, MD-44 - Drain Assembly
1 100036 TEE, 1-1/2" NPT GALVANIZED 1
2 100043 NIPPLE, 1-1/2" NPT X CLOSE, GALVANIZED 1
3 100140 HEX PLAIN NUT, 3/8-16 SST 2
4 100512 ELBOW, 1" NPT X 90° SST 1
5 100735 BOLT, HEX HD., 1/4-20 X 5/8" SST 2
6 100736 BOLT, HEX HD., 1/4-20 X 3/4" SST 4
7 102376 WASHER, FLAT 5/16" SST 4
8 102563 BOLT, HEX HD., 3/8-16 X 3/4" SST 2
9 106407 WASHER, LOCK 3/8" SPLIT SST 2
10 106482 WASHER, LOCK 1/4" SPLIT SST 6
11 107340 CLAMP, HOSE M28 SST GEAR-TYPE 2
12 108345 GASKET 1
13 111034 DRAIN BODY, MACHINED 1
14 111097 BUSHING, REDUCING, 1-1/2" NPT X 1" NPT GALV. 1
15 114185 GRIP, DRAIN HANDLE 1
16 114472 HOSE, OVERFLOW 1
17 114718 VALVE, BALL 1-1/2" UNION END WITH TEE HANDLE 1
18 114817 SLEEVE BEARING, 1/2" DIA. ROD NYLON 1
19 204383 NIPPLE, TOE, 1"NPT X 2" LG., GALV. 1
20 207190 NIPPLE, TOE, 1" NPT X 19" LG., GALV. 1
21 304816 STRAINER, DRAIN 1
22 333268 DRAIN HANDLE WELDMENT 1
23 333511 BRACKET, DRAIN LEVER SUPPORT 1
NS
114825 NAMEPLATE, DRAIN 1
--- 602030 PIPING ASSY, DRAIN 1
(INCLUDES ITEMS 1,2, 13-15, 17, 19, 22)
69
Item
No. Part No. Description Qty.
