All Models - Fill Piping
1 100135 GAUGE, PRESSURE 0-60 PSI 1
2 100171 BUSHING, RED. FACE 3/4" X 1/2" BRASS 1
3 100184 NIPPLE, 3/4" NPT X CLOSE BRASS 8
4 100206 NIPPLE, 1/2" NPT X 2-1/2" LG. BRASS 1
5 100209 NIPPLE, 1/2" NPT X CLOSE BRASS 3
6 100500 VACUUM BREAKER, 1/2" NPT BRONZE 1
--- 900836 KIT, REPAIR 1/2" VACUUM BREAKER A/R
7 100571 UNION, 3/4" NPT BRASS 2
8 100599 CROSS, 3/4" NPT BRASS 2
9 100709 LOCKNUT, 1/2" NPT BRASS 1
10 101259 PLUG, 1/8" NPT SQ. HEAD BRASS 1
11 101397 NIPPLE, RTOE, 1/2" NPT X 7" LG. BRASS 1
12 102388 BUSHING, REDUCING 1/2" NPT X 1/4" NPT BRASS 1
13 102392 BUSHING, REDUCING, 3/4" NPT X 1/2" NPT BRASS 3
14 102435 ELBOW, 1/2" NPT X 90° BRASS 1
15 102438 ELBOW, STREET, 1/2" NPT X 90° BRASS 1
16 102442 ELBOW, 3/4" NPT X 90° BRASS 2
17 102444 ELBOW, STREET, 3/4" NPT X 90° BRASS 1
18 102470 NIPPLE, 3/4" NPT 3" LG. BRASS 1
19 102505 PLUG, 3/4" NPT, SQ. HEAD BRASS 1
20 102525 TEE, RED, 3/4" X 1/2" X 3/4" NPT BRASS 1
21 102549 UNION, 1/2" NPT BRASS 1
22 104429 VACUUM BREAKER, 3/4" BRASS 1
--- 900837 KIT, REPAIR VACUUM BREAKER 3/4" A/R
23 105976 BUSH, RED, 3/4" X 1/8" BRASS 1
24 107550 VALVE, PRESSURE REGULATING 3/4" NPT BRONZE 1
25 109886 VALVE, SOLENOID, 1/2" NPT, HW PARKER 1
--- 109902 KIT, REPAIR SOLENOID 1/2" HW A/R
--- 108516 COIL, SOLENOID, 1/2" HW, 120VAC A/R
26 110768 STRAINER, LINE 3/4" NPT BRONZE 1
27 111437 VALVE, SOLENOID 3/4" NPT HW 1
--- 109903 KIT, REPAIR 3/4" SOLENOID VALVE A/R
--- 111472 COIL, SOLENOID 3/4" 120VAC A/R
28 115101 CONNECTOR, MALE, 1/2" NPT X 1/2" 37° FLARE BRASS 2
29 201029 LOCKNUT, 1/2" NPT NP 1
30 333654 BRACKET, FILL PIPING SUPPORT 1
31 419009 FILL HOSE ASSY 1/2" ID X 22" LG FLARE JIC 1
(For L-R machines without booster)
32 419005 FILL HOSE ASSY 1/2" ID X 60" LG FLARE JIC 1
(For R-L machine without booster)
47
Item
No. Part No. Description Qty.
