S41i CO2 Incubator Shaker — Operating manual
32
5.5.4 SUMMARY screen
Abb. 17: Summary view button
Fig. 17: Summary view button
 Press the Summary View button to open the SUMMARY screen.
Like the STATUS screen, the SUMMARY screen has a START button which, once it has been
pressed to launch operation, becomes a STOP button to allow you to stop operation.
If the icon appears, an alarm condition exists. This needs to be acknowledged and rectified.
Go to the ALARMS screen (see ALARM SETTINGS screen on p. 30).
The presence of the open LOCK icon indicates that the user screens are unlocked for access
to make changes. When the padlock is closed, the screens are locked against changes;
Admin level security is required to make edits.
The following table identifies the five values (parameters) that may appear in abbreviated
form in the lefthand column of the SUMMARY screen:
As with the STATUS screen, press any Setpoint to open that parameter’s screen to set or
reset the Setpoint.
When you set a Run Time, the STOPWATCH icon appears next to RPM in the SUMMARY
screen, too:
Hint!
If your incubator/shaker is not equipped with a humidity sensor, your SUMMARY screen will not
indicate RH (Relative Humidity).
O
2
option not available.
Abbreviation Value
Temp Temperature (°C)
CO
2
Carbon Dioxide (%)
RPM Shaking speed (rpm)
RH Relative Humidity (%)
5
Operation
