Section
7.2
7-12 A38E Work Platform
Illustrated Parts Breakdown
CAGE ROTATOR ASSEMBLY(OPTION)
500905-000
(501864-000 is not included as part of this assembly)
Note : Ensure that items 11 (M16 screw and drilled
nut with pin) rema in loose, these are safety bolts.
(ANSI is Without Overload)
ITEM PART NO. DESCRIPTION QTY.
1 513433-002 UPPER CONTROL BOX - CE 1
* 513433-003 UPPER CONTROL BOX - ANSI 1
2 500973-001 MOUNTING PLATE 1
3 500985-000 ROTATING HANDLE 1
4 500922-000 GEARBOX 1
5 500905-034 HANDLE 1
6 500905-030 DRIVE SHAFT 1
7 508931-001 DROP BAR ASSY 1
8 057521-001 CAGE RAIL ASSY 1
9 501970-000 WELDMENT, CAGE BASE 1
10 513160-000 OVERLOAD UNIT - CE 1
* 513161-000 LOAD CELL HARNESS - 1
* 509791-000 REPLAMENT BLOCK - ANSI 1
11 509595--000 M16 BOLT + NUT CROSS DRILLED
12 056069-016 M16 WASHER 8
13 503101-040 M16 X 40 HEX HEAD SCREW 8
14 512321-000 DISC, FRICTION 2
2
15 501971-001 CAGE CRADLE WELDMENT 1
16 500993-000 45MM BRUSHING X 30mm LONG 2
17 501972-000 WELDMENT, CAGE LINK 1
#
18
19 057347-001 LADDER
1
20 058251-000 LOCKING CATCH 1
21 057405-000 LADDER BUSHING 2
22 512782-000 POLL PIN ROTATE LINK 1
23 500905-018 CAGE PIVOT PIN 1
24 504189-001 STEEL FLAT WASHER, M48 X 4mm 1
25 056067-545 HEX JAM NUT, M45 2
######-### ####
