A38E Work Platform

Illustrated Parts Breakdown

MOTOR/PUMP ASSEMBLY

057530-000

NOTE:

THE PART NUMBER FOR THE

MOTOR ASSEMBLY (ALL ITEMS FROM

2 TO 17) IS 058861-000

ITEM PART NO. DESCRIPTION

QTY.

1

058862-000 HYDRAULIC PUMP

1

*

058862-001 SEAL KIT

1

2

058847-000 COUPLING

1

3

─

OIL SEAL

1

4

─

PUMP MOUNTING FACE

1

5

─

CIRCLIP

1

6

─

BEARING

1

7

─

CIRCLIP

1

8

─

CIRCLIP

1

9

─

COOLING FAN

1

10

─

COMMUTATOR

1

11

─

BEARING

1

12

─

COMMUTATOR COVER

1

13

─

BRUSH HOUSING SUPPORT

1

14

058863-000 BRUSH

4

15

─

END HOUSING

1

16

─

TERMINAL BLOCK

1

17

─

VENT/ INSPECTION CAP

4
