Section
7-18 A38E Work Platform
7.2
Illustrated Parts Breakdown
TRACTION MOTOR ASSEMBLY
512944-000
ITEM PART NO. DESCRIPTION QTY.
1 512944-001 SEAL 1
2 512944-002 DRIVE END HEAD 1
3 512944-003 WAVY WASHER 1
4 512944-004 DRIVE END BEARING 1
5 512944-005 FAN 1
6 512944-006 ARMATURE ASSEMBLY 1
7 512944-007 COMMUTATOR 1
8 512944-008 SHIM 1
9 512944-009 FRAME AND FIELD ASSEMBLY 1
10 512944-010 POLE PIECE 1
11 512944-011 FIELD COIL 1
12 512944-012 SPRING 1
13 512944-013 BUSH 1
14 512944-014 BRUSH BOX ASSEMBLY 1
15 512944-015 RETAINING RING 1
16 512944-016 COMMUTATOR END BEARING 1
17 512944-017 COMMUTATOR END HEAD 1
SERIAL BREAK: (SN:006001 - 006281 / 006523 - ######)
